Sunny Highpower PEAK3 100-21, 100 kW

The Sunny Highpower PEAK3 series from SMA is the central component for large PV power plants. System voltages up to 1500 V DC and the use of customer-specific generator connection boxes enable efficient project calculation. Thanks to high-quality system components, there is no derating up to a temperature of 50C.

Product advantages:

? Up to 200% DC/AC ratio possible

? AC+DC type 2 overvoltage protection

Product features:

? AC rated power: 100.0 kW

? Feed-in phases: 3

? AC mains voltage: 400 V

? Number of MPPT: 1

? Max. DC input voltage: 1100 V

? DC overvoltage protection: Type 2

? AC overvoltage protection: Type 2

? DC connector: Bolt terminal for cable lug up to 300 mm?

? Interfaces: 2 x Ethernet

? Protection class: IP65

? Cooling: active

? Dimensions: 830 x 770 x 462 mm (H x W x D)

? Weight: 99.0 kg
