Verto 33.3

With its new Verto series, Fronius is bringing a breath of fresh air to the power classes from 25 to 33.3 kW. High flexibility thanks to 4 MPP trackers. Maximum safety thanks to integrated arc detection Arc Guard and overvoltage protection on AC and DC connections. Thanks to open interfaces, universal application options for energy management with Wattpilot, Ohmpilot & Co. The integrated data logger also has numerous connection options for external control signals or load management.

Product advantages:

? 28 A input current per MPPT / string

? Integrated AC+DC overvoltage protection type 1+2

? Integrated AFCI arc detection

? Integrated data logger + web server

Product features:

? AC power: 33.3 kW

? AC connection: 400 V, 3-phase

? Number of MPPT: 4

? DC input current: 28 A per MPPT / string

? Connections per MPPT: 2

? DC connection: Stubli MC4

? Communication: WLAN, LAN

? Interfaces: 2 x RS485, 6 x DI, 6 x DI / DO (FRE)

? Protection class: IP66

? Cooling: active

? Dimensions: 865 x 574 x 279 mm (H x W x D)

? Weight: 41.75 kg

? Warranty: 2 years + a further 3 years after free registration
